UniGear ZS1 adopts the advanced design concept. The performance is comprehensively improved and integration of IoT and digital technology make the operation of substation easier and safer. It has passed the compulsory test items stipulated by IEC Standard.
500 mm panel width, most compact air-insulated switchgear with withdrawable VD4 circuit breaker.
Polyamide poles circuit breakers with excellent mechanical and electrical endurance capability.
Innovative safety operation assistance system prevents electric shock and ensures personal safety.
Real-time monitoring and asset health management transition from preventive to predictive maintenance.
| Parameter | Single Busbar | Double Busbar / Duplex | Double Level |
|---|---|---|---|
| Max. Rated Voltage | 24kV | 24kV | 17.5kV |
| Max. Continuous Current | 4000 A | 4000 A | 1600 A |
| Short-time Withstand Current | 63 kA | 31.5 kA | 50 kA |
| Busbar Configuration | Single | Double / Back-to-Back | Double Level |
The UniGear ZS1 offers a compact 500mm panel width, making it one of the most space-efficient air-insulated switchgears available. It also integrates IoT technology for smarter asset management.
It supports up to 24kV for single and double busbar configurations, and up to 17.5kV for double-level designs.
Yes, the UniGear ZS1 has passed all compulsory test items stipulated by the IEC Standard, ensuring high reliability and safety.
Through multidimensional real-time monitoring and analysis, the system shifts maintenance from traditional preventive schedules to predictive maintenance, reducing costs and downtime.
The switchgear can withstand a rated short-time current of up to 63kA, providing robust protection for electrical systems.
It utilizes withdrawable VD4 circuit breakers with polyamide poles, which are known for their high breaking capacity and durability.
