Indoor Environment-Friendly 11kv 12kv Dry Air C-Gis Gas-Insulated Switchgear

1 / 5

Indoor Environment-Friendly 11kv 12kv Dry Air C-Gis Gas-Insulated Switchgear

Customization:	Available
Certification:	ISO9001, IEC62271
Shell Material:	Steel Plate

Send Inquiry

Product Description

Basic Info.

Model NO.

ZCKQC-12

Voltage Level

Medium Voltage

Installation

Fixed

Structure

Floorstanding

Current

Rated Voltage

12kv

Loss of Service Continuity

Lsc2a

Height

2200/2400mm

Width

600/800/900mm

Depth

1200/1400/1600mm

Transport Package

Aluminum Foil + Wooden Pallet

Trademark

Customized

Origin

China

Product Description

Indoor Environment-friendly 11kV 12kV Dry Air C-GIS Gas-insulated Switchgear

Serial number	Item	Unit	Data
1	Rated voltage	kV	12
2	Rated frequency	Hz	50/60
3	Rated current	A	1250/2500/3150
4	Rated power frequency withstand voltage	kv	42
5	Rated short-time withstand current	kA	31.5/40
6	Rated peak withstand current	kA	80/100
7	Duration of rated short-circuit current	s	4
8	Rated short-circuit breaking current	kA	31.5/40
12	Insulating gas	-	Dry Air
14	Degree of protection (Sealed gas box)	-	IP67
17	Mechanical life (Circuit breaker)	Operation	10000

Standards & Specifications

IEC 62271-1: 2021 High-voltage switchgear and controlgear - Common specifications
IEC 62271-100: 2021 Alternating-current circuit breakers
IEC 62271-102: 2022 Alternating current disconnectors and earthing switches
IEC 62271-103: 2021 Alternating current switches (1 kV to 52 kV)
IEC 62271-200: 2021 AC metal-enclosed switchgear and controlgear
IEC 61869-2:2012 Instrument transformers - Current transformers
IEC 60529: 1989 Degrees of protection provided by enclosures (IP Code)

Product Gallery

Frequently Asked Questions (FAQ)

Q: What is the main insulation medium used in this C-GIS switchgear? A: This model uses Dry Air as the environmentally friendly insulating gas.

Q: What is the rated voltage of this switchgear system? A: It is designed for 12kV medium voltage power distribution applications.

Q: What is the degree of protection for the sealed gas box? A: The sealed gas box features an IP67 protection rating, ensuring high reliability.

Q: Is this equipment suitable for indoor installation? A: Yes, it is specifically designed as an Indoor Environment-friendly C-GIS switchgear.

Q: What is the mechanical life of the circuit breaker? A: The circuit breaker has a mechanical life of 10,000 operations.

Product Detail

Indoor Environment-Friendly 11kv 12kv Dry Air C-Gis Gas-Insulated Switchgear

Product Description

Basic Info.

Product Description

Standards & Specifications

Product Gallery

Frequently Asked Questions (FAQ)
