Product Description

Power Substation Transformer
📦

Product Description

Electrical Panel Details
📋

Technical Specification

No. Item Unit Technical Parameters
1Rated VoltagekV40.5
2Rated FrequencyHz50
3Rated CurrentA1250 / 1600 / 2000 / 2500
4 Rated Insulation Level 1 min power frequency voltage Phase to earth kV 95
Across isolation distance110
Lightning impulse voltage Phase to earth 185
Across isolation distance215
5Rated Short-Circuit Breaking Current (RMS)kA2531.5
6Rated Short-Time Withstand Current (RMS)kA2531.5
7Rated Short-Circuit Making Current (Peak)kA6380
8Rated Peak Withstand CurrentkA6380
9Rated Duration Of Short-Circuitss4
10Degrees of Protection-IP3X
11Control Circuit Rated VoltageVDC/AC 110/220
12Weightkg2000-3000
13Mechanical Endurancetimes1000
14Dimensions (W x D x H)mm2020*3200*3600
Note: Specific dimensions may be determined based on the preliminary layout drawings.
Technical Drawing
🏭

Factory Display

Factory Overview
Production Line
Quality Control
🚚

Packaging & Shipping

Packaging Logistics
🎖

Certifications

Quality Certifications
❓

Frequently Asked Questions

What main electrical products do you supply?
We mainly supply LV/MV (0.4kV-40.5kV) distribution cabinets, circuit breakers, box substations, pole mounted switches and related electrical supporting parts.
Do you accept OEM/ODM?
Yes, we do. Our professional engineering team can customize products according to your drawings or specific requirements.
What is the standard delivery time?
It depends on your order quantity and specifications, usually it takes about 15-20 working days for production.
How is the product quality ensured?
We have a strict QC team and complete testing process. Every product is fully tested before shipment, and we can provide test photos or videos upon request.
What payment terms are accepted?
We accept T/T and other terms can be discussed based on the specific order details.
What after-sales service is provided?
We provide online technical support at any time. If you encounter any issues during use, we will respond and provide solutions in a timely manner.
